Specs
Engine
- Engine Brand Kohler®
- Engine Model Confidant EFI
- Engine Model Number EZT750
- Engine Displacement 747cc
- Engine Output 27HP
- Fuel Tank Capacity Dual 3.5 gal. US (13.25 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge No
- Choke Auto-Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Electronic Fuel Injection (EFI)
Drive System
- Transmission 12cc Hydro-Gear® ZT 3400 with charge pumps
- Forward Speed 9.5 mph / 15 km/h
- Reverse Speed 4.5 mph / 7 km/h
Cutting Deck
- Deck Cutting Width 54 in
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction Floating, fabricated 10ga. (.135”) steel shell (e-coated)
- Spindle Construction 5" sealed cast aluminum housing (maintenance-free)
- Blade(s) 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range 1” to 5” in 1/4” increments
- Anti-Scalping 4 Front HD w/ Bushings & Grease Zerk
- Deck Positions Hand Lever / 15 position / spring assist
Chassis
- Frame Fully welded, full-legnth 12ga. channel frame with 14ga. reinforcements
- Front Axle 2" x 3" solid steel
- ROPS 2" x 2" quick-latch tool-less foldable 3 position
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Yokes 3/8" thick steel with sealed ball bearing front yokes
Controls
- Cruise Control Standard - Foot operated pedal engagement
- Brakes Foot-operated pedal
- Steering Control High Performance Steering Wheel with Foot-pedal Control
Comfort
- Seat Type Cushion with seat belt
- Armrests adjustable arm rests
- Seat Suspension High-back suspension
Wheels
- Rear Tires 23"x 10.5"-12"
- Front Tires 13"x6.5"-6" turf
- Tire Tread Turf Master
Dimensions
- Dimensions L/W/H 80" L x 56" W x 48" H
- Weight (approx.) 1000 lbs.
Additional Specifications
- Hour Meter Basic Hour Meter (no tach)
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Intergrated into Side Pod
- Model Number 53TWEFJA050
Warranty
- Warranty 4-year/500-hour limited residential warranty
- Commercial Warranty 2-year limited commercial warranty (no hour limitations)
