Specs
| Feature | Specifications |
|---|---|
| Engine | 25.5 hp Kawasaki® FX801V |
| Horsepower | 25.5 |
| Cylinders | 2 |
| Oil Capacity | 2.1 qt (2 L) |
| Drive System | Hydro-Gear® ZT-4400 |
| Hydro Oil Cooler | N/A |
| Fuel Capacity | 10.25 Gallon |
| Steering Control | Joystick, Twin Lever |
| Stand-up Deck | Standard |
| Pivoting Front Axle | Standard |
| Roll-Over Protection | Standard |
| Tires, Rear | 24x9.5-12, 24x12-12 |
| Tires, Front | 13x6.5-6 |
| Turning Radius | Zero-Turn |
| Ground Speed (Forward/Reverse) | 11 mph/6 mph |
| Length | 84" |
| Height : top of seat back | N/A |
| Height : top of ROPS extended | 74" |
| Height : top of ROPS folded | 47" |
| Width, Tractor (outside rear tires) | 51", 56" |
| Width, Deck w/ Chute | 65", 73" |
| Width, Deck Chute Up | 53", 61" |
| Cutting Width | 52", 60" |
| Cutting Height | 1.5" - 5" (1/4" increments) |
| Deck Construction | Laminated Welded 10 Gauge Steel Deck with 10 Gauge Reinforcement and additional 7 Gauge Spindle Mounting Reinforcement, protective bullnose front, high impact anti-scalp rollers, and wear bar |
| Deck Engagement | Electric, Warner® |
| Blade Length | 18.375", 21" |
| Spindle Assembly | Cast iron housing; 1.5" diameter shaft; maintenance free & field serviceable |
| Blade Tip Speed, approx. | 19,000 fpm |
| Weight | 1028 lbs - 1273 lbs |
| Seat | Suspension Seat with 2-1/4" Adjustable Travel, Vibration Isolators, Adjustable Seat Back Recline, Seat Back Pocket and Adjustable Arm Rests |
| Other Standard Features | Hour Meter, Electric Start, Cup Holder, Storage Tray, Front Step, Float Fuel Gauge, Trailer Hitch Receiver |
